Advanced Machining Capabilities
With an eye toward the future, we evaluate new trends, technology, and best practices available on the market. Shamrock Precision’s objective is to provide high-precision products that meet strict customer specifications through our expansive machining capabilities. We ensure all components are delivered on time with a commitment to the continual improvement of our manufacturing processes.
Capabilities
Industry Standards
| Swiss Machine | Swiss Machine |
|---|---|
| AS9100:2016 | AS9100:2016 |
| ISO9001:2015 | ISO9001:2015 |
Outer Diameter
| Swiss Machine | CNC Machine |
|---|---|
| Min: 0.03" (0.75 mm) | Min: 0.062" (2 mm) |
| Max: 0.787" (20 mm) | Max: 1.0" (25 mm) Colleted |
| Max: 8.0" (200 mm) Chucked |
Overall Length
| Swiss Machine | CNC Machine |
|---|---|
| Min: 0.04" (1 mm) | Min: 0.35" (8 mm) |
| Max: 7.9" (197 mm) | Max: 10.0" (250 mm) |
Materials
| Swiss Machine | CNC Machine |
|---|---|
| Alloy Steels(4130, 4140, 4142, 4340, 6150, 8630) | Inconel(925, 725, 718, 625, 600, 945) |
| Aluminum(2011, 6061-T4-T6, 2024-T3-T4, 7075-T3) | Monel(K500, K400, R405) |
| Aluminum Bronze | MP35N |
| Berryllium Copper | Stainless Steel (302, 303, 304, 316, 410, 416, 420, 17-4, A-286) |
| Brass(360, 464, 660) | Super Alloys (13 Super Chrome, Hyperchrome, CR9, CR13, CR23) |
| Bronze Alloys(675) | Super-Duplex |
| Carbon Steel (1018, 12L14, 1215, 1045) | Specialty per Customer Specification |
Tolerance
| Swiss Machine | CNC Machine |
|---|---|
| .0005 inches (0.0125 mm) | .0005 inches (0.0125 mm) |
| Tight Tolerances | Tight Tolerances |
| Precision | Precision |
| Ultra Precision |
Products
| Swiss Machine | CNC Machine |
|---|---|
| Shear Screws & Shear Pins | |
| Shear Screws of sizes 0.125" – 0.875” diameter | Shear Pins with or without Knurled heads |
| Shear Screws with full thread | Shear Pins of various sizes |
| Shear Screws with Dog Point or Half-Dog Point | Groove Pins of various sizes and materials |
| Precision Machined Components | |
| Specialty fasteners to customer specifications | Hose Connectors |
| Adapters | Machine Screws |
| Bearing Sleeves | Hose Connectors |
| Bolts | Protective Washer |
| Bushings | Socket Head Cap Screws |
| Bridging Plugs | Set Screws |
| Connectors | Studs |
| Fittings | Spacers |
| Gauge Ports | Special Screws |
| Gold Plated Contact Pins | Special Screws |
| Guide Pins | Parts made to customer specification |
| Machined Components for Packers, Liner Hangers, Artificial Lift, Cementing, and Completino Tools | |
| Release Sleeves | Centralizer Running Tools |
| Shear Ring Retainer | Latch Components for Pulling Tools |
| Packer Assembly Guide | Slip Housings |
| Packer Mandrels | Upper Drill Pipe Spinner |
| Shear Sub for Packers | Artificial Lift Shaft Components |
| Slip Cage for Retrievable Packers | Cementing Seat Opening/Closing |
| Mandrel Crossovers | Components made to customer specification |
| Centralizer Cages | |
| Distribed Standard Fasteners | |
| Cap Screws | Cap Nuts |
| Hex Head Cap Screws | Dowel Pins |
| Machine Screws | Knurled Pins |
| Sheet Metal Screws | Grooved Pins |
| Thread Cutting Screws | Slotted Spring Pins |
| Self-Drilling Screws | Coiled Pins |
| Lag Screws | Imperial and Metric Fasteners |
| SEMS Screws (Screw and Washer Assemblies) | Modified Holo-Krome parts |
| Eye Screws | Roll Pins |
| Flat Washers | Clevis Pins |
| Lock Washers | Cotter Pins |
| Beveled Washers | Retaining Rings |
| Square Washers | Pop Rivets |
| Conical Washers | Structure Bolts |
| Wave Washers | O-Rings |
| Belleville Washers | Grommets |
| Hex Bolts | Standoff - Hex - Round |
| Carriage Bolts | Spacer - Nylon |
| Flange Bolts | Cable Tie Wraps |
| Square Head Bolts | Hex Keys |
| U-Bolts | All Thread Rods |
| Hanger Bolts | Treaded Inserts |
| Eye Bolts | Tinnerman Nuts / Clips |
| Connector Bolts | Grease Fittings |
| Hex Nuts | Tamper Proof Screws |
| Lock Nuts | Sex Screws |
| Jam Nuts | Wall Anchors |
| Flange Nuts | Concrete Screws |
| Wing Nuts | Drywall Screws |
| Heavy Hex Nuts | Thread Checkers |
| Square Nuts, Spring Nuts | Rod Ends - Turnbuckles |
| Thumb Screws | |
File Formats
| Swiss Machine | CNC Machine |
|---|---|
| PDF (Preferred format, however 3D models are helpful in addition) | Autocad |
| DXF | BMP |
| DWG | IGES |
| Solid Works (SLDPRT, SLDDRW, DLDDRT) | JPEG |
| JPG | |
| STEP |
Products
Manufactured
| Shear Screws & Shear Pins | |
|---|---|
| Shear Screws of sizes 0.250" – 0.875” diameter | Shear Pins with or without Knurled heads |
| Shear Screws with full thread | Shear Pins of various sizes |
| Shear Screws with Dog Point or Half-Dog Point | Groove Pins of various sizes and materials (commonly referred toas Driv-Lok pins) |
| Precision Machined Components | |
| Specialty fasteners to customer specifications | Hose Connectors |
| Adapters | Machine Screws |
| Bearing Sleeves | Modified Fasteners |
| Bolts | Protective Washer |
| Bushings | Socket Head Cap Screws |
| Bridging Plugs | Set Screws |
| Connectors | Studs |
| Fittings | Spacers |
| Gauge Ports | Special Screws |
| Gold Plated Contact Pins | Modified Fasteners |
| Guide Pins | Parts made to customer specification |
| Machined Components for Packers, Artifical Lift, Cementing, and Completion Tools | |
| Release Sleeves | Centralizer Running Tools |
| Shear Ring Retainer | Latch Components for Pulling Tools |
| Packer Assembly Guide | Slip Housings |
| Packer Mandrels | Upper Drill Pipe Spinner |
| Shear Sub for Packers | Artificial Lift Shaft Components |
| Slip Cage for Retrievable Packers | Cementing Seat Opening/Closing |
| Mandrel Crossovers | Components made to customer specification |
| Centralizer Cages | |
DistributedStandard Fasteners
| Cap Screws | Cap Nuts |
| Hex Head Cap Screws | Dowel Pins |
| Machine Screws | Knurled Pins |
| Sheet Metal Screws | Grooved Pins |
| Thread Cutting Screws | Slotted Spring Pins |
| Self-Drilling Screws | Coiled Pins |
| Lag Screws | Imperial and Metric Fasteners |
| SEMS Screws (Screw and Washer Assemblies) | Modified Holo-Krome parts |
| Eye Screws | Roll Pins |
| Flat Washers | Clevis Pins |
| Lock Washers | Cotter Pins |
| Beveled Washers | Retaining Rings |
| Square Washers | Pop Rivets |
| Conical Washers | Structure Bolts |
| Wave Washers | O-Rings |
| Belleville Washers | Grommets |
| Hex Bolts | Standoff - Hex - Round |
| Carriage Bolts | Spacer - Nylon |
| Flange Bolts | Cable Tie Wraps |
| Square Head Bolts | Hex Keys |
| U-Bolts | All Thread Rods |
| Hanger Bolts | Treaded Inserts |
| Eye Bolts | Tinnerman Nuts / Clips |
| Connector Bolts | Grease Fittings |
| Hex Nuts | Tamper Proof Screws |
| Lock Nuts | Sex Screws |
| Jam Nuts | Wall Anchors |
| Flange Nuts | Concrete Screws |
| Wing Nuts | Drywall Screws |
| Heavy Hex Nuts | Thread Checkers |
| Square Nuts, Spring Nuts | Rod Ends - Turnbuckles |
| Thumb Screws |
Turning & Machine Centers (CNC)
Turning centers - CNC
| (4) Citizen-Cincom A20 Swiss Lathes | 5-Axis Swiss Lathe |
|---|---|
| 0.87” Bar Capacity, Automatic Bar Feed | |
| Guide Bushing and Subspindle | |
| (6) Mazak QT Nexus 250 Lathes | 6" CHUCK / 5C COLLET |
| 1.625" THROUGH SPINDLE | |
| SUBSPINDLE | |
| (4) Mazak QT Nexus 100M Lathes | 6" CHUCK / 5C COLLET |
| 1.625" THROUGH SPINDLE | |
| SUBSPINDLE | |
| (1) Mazak QT Nexus 250M Lathe | 10" CHUCK / 3J COLLET |
| 8" TURNING DIA. | |
| 3" BAR CAPACITY, BAR FEED | |
| LIVE TOOLING | |
| (1) Mazak QT Nexus 350 MSY Lathe | 15" MAIN CHUCK, 13" DIA. |
| 10" SUBSPINDLE | |
| LIVE TOOLING | |
| (4) Mazak QT Nexus 250 Lathes | 10" CHUCK / S30 COLLET |
| 8" TURNING DIA. | |
| 3.0" BAR CAPACITY, BAR FEED |
Machining Centers - CNC
| (1) Mazak Nexus 510C / 50-II Mill | 20" X 40" X 24" |
|---|---|
| Full 4th Axis | |
| Cat 50 Tooling | |
| (1) Mazak VTC 20B Mill | 20" X 40" X 24" |
| Full 4th Axis | |
| Cat 40 Tooling | |
| (1) Makino a500Z | Horizontal Machininig 5-Axis |
| Automatic Pallet Changer |
Raw Materials
Super Alloy
| Inconel (925, 725, 718, 625, 600, 945) |
| Monel (K500, K400, R405) |
| 13 Super Chrome, Hyperchrome |
| MP35N |
| CR9, CR13, CR23 |
Stainless Steel
| 302, 303, 304, 316 |
| A-286 |
| 17-4PH |
| 410, 416, 420 |
| Super-duplex |
Steel
| C1018, C1215, 1045, 12L14, 6150 |
| 4140, 4142, 4130, 4340 |
Aluminum
| 2011-T3-T4, 2024-T3-T4 |
| 6061-T4-T6, 7075-T3 |
Brass
| 360, 464, 660 Brass |
| Manganese Bronze |
| Aluminum Bronze |
| Beryllium Copper |
Inspection
Inspection
| Brown & Sharp CMM Inspection — 27" X 39" X 25" Travel | (3) S-T Industries 3700 W/M2 — Optical Comparator |
| Oasis Optical Inspection System — 0.0001 Inches Accuracy | Clark CR-1e — Hardness Testing |
| (3) Keyence Image Measurement — 0.0001 Inches Accuracy | Clark CR-1xl — Hardness Testing |
| (4) Test Mark CM-2500-SD — Compression Testing | Gagemaker Mic Trac — MT-3000 |
